Symbol Math Instructions Section 3-11
Description *UL(423) multiplies the unsigned binary values in Md and Md+1 and Mr and
Mr+1 and outputs the result to R, R+1, R+2, and R+3.
Flags
Precautions When *UL(423) is executed, the Error Flag will turn OFF.
If as a result of the multiplication, the content of R, R+1, R+2, R+3 is 0000
hex, the Equals Flag will turn ON.
If as a result of the multiplication, the content of the leftmost bit of R+3 is 1,
the Negative Flag will turn ON.
Examples When CIO 000000 is ON in the following example, D00100, D00110, D00111,
and D00110 will be multiplied as 8-digit unsigned binary values and the result
will be output to D00123, D00122, D00121, and D00120.
EM Area without bank E00000 to E32766 E00000 to
E32764
EM Area with bank En_00000 to En_32766
(n = 0 to C)
En_00000 to
En_32764
(n = 0 to C)
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants #00000000 to #FFFFFFFF
(binary)
---
Data Registers ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Area Md Mr R
R + 1 RR + 3 R + 2
Md + 1 Md
Mr + 1 Mr
(Unsigned binary)
(Unsigned binary)
(Unsigned binary)
×
Name Label Operation
Error Flag ER OFF
Equals Flag = ON when the result is 0.
OFF in all other cases.
Negative Flag N ON when the leftmost bit of the result is 1.
OFF in all other cases.
