Conversion Instructions Section 3-12
■ Example 1: Converting to Binary Data with an 8-bit Resolution and Zero
Point Offset of 001A Hex
■ Example 2: Converting to Angle Data with a 10-bit Resolution and Zero
Point Offset of 0151 Hex
0 0
C: D00000
0
80
4 3 7 8111215
001A
C+1: D00001
S: 0010 1001010000000000
0017
D: D00200
0000
D+1: D00201
000
C+2: D00002
0
Operating mode: Gray binary code conversion
Conversion mode: Binary Mode
Resolution: 8-bit
Zero point offset: 001A hex
User-specified resolution: Not used.
Gray binary code
Converted and offset.
Result of binary conversion and offsetting stored.
0 2
C: D00000
0
A0
4 3 7 8111215
0151
C+1: D00001
S: 0010 1001010110000000
3488
D: D00200
0000
D+1: D00201
000
C+2: D00002
0
Operating mode: Gray binary code conversion
Conversion mode: 360° Mode
Resolution: 10-bit
Zero point offset: 0151 hex
User-specified resolution: Not used.
Gray binary code
Converted and offset.
Angle data stored.
