Logic Instructions Section 3-13
Description ORWL(611) takes the logical OR of data specified in I
1
and I
2
as double-word
data and outputs the result to R, R+1.
• When any of the corresponding bits in I
1,
I
1
+1, I
2,
and I
2
+1are 1, a 1 will
be output to the corresponding bit it R+1. When any of them are 0, a 0 will
be output to the corresponding bit in R+1.
(I
1,
I
1
+1) + (I
2,
I
2
+1) → (R, R+1)
Flags
Precautions When ORWL(611) is executed, the Error Flag will turn OFF.
If as a result of the OR, the content of R, R+1 is 00000000 hex, the Equals
Flag will turn ON.
If as a result of the OR, the leftmost bit of R+1 is 1, the Negative Flag will turn
ON.
EM Area with bank En_00000 to En_32766
(n = 0 to C)
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants #00000000 to #FFFFFFFF
(binary)
---
Data Registers ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
Area I
1
I
2
R
I
1,
I
1
+1 I
2,
I
2
+1 R, R+1
111
101
011
000
Name Label Operation
Error Flag ER OFF
Equals Flag = ON when the result is 0.
OFF in all other cases.
Negative Flag N ON when the leftmost bit of R is 1.
OFF in all other cases.
