Instruction Classifications by Function Section 2-1

Block

program-

ming

instructions

Define block pro-

gram area

BPRG BLOCK PRO-

GRAM BEGIN

BEND BLOCK PRO-

GRAM END

--- ---

Block

program start/stop

BPPS BLOCK

PROGRAM

PAUSE

BPRS BLOCK

PROGRAM

RESTART

--- ---

EXIT EXIT

bit_address

Conditional

END

EXIT NOT

bit_address

Conditional

END NOT

input_condition

EXIT

Conditional

END

IF branch

processing

bit_address

CONDI-

TIONAL

BLOCK

BRANCHING

IF NOT

bit_address

CONDI-

TIONAL

BLOCK

BRANCHING

(NOT)

ELSE CONDI-

TIONAL

BLOCK

BRANCHING

(ELSE)

IEND CONDI-

TIONAL

BLOCK

BRANCHING

END

--- --- --- ---

WAIT WAIT

bit_address

ONE CYCLE

AND WAIT

WAIT NOT

bit_address

ONE CYCLE

AND WAIT

NOT

input_condition

WAIT

ONE CYCLE

AND WAIT

Timer/

counter

BCD TIMW HUNDRED-

MS TIMER

WAIT

CNTW COUNTER

WAIT

TMHW TEN-MS

TIMER WAIT

Binary* TIMWX HUNDRED-

MS TIMER

WAIT

CNTWX COUNTER

WAIT

TMHWX TEN-MS

TIMER WAIT

Repeat LOOP LOOP BLOCK LEND

bit_address

LOOP BLOCK

END

LEND NOT

bit_address

LOOP BLOCK

END NOT

input_

condition

LEND

LOOP BLOCK

END

--- --- --- ---

Text string

processing

instructions

--- MOV$ MOV STRING +$ CONCATE-

NATE

STRING

LEFT$ GET STRING

LEFT

RIGHT$ GET STRING

RIGHT

MID$ GET STRING

MIDDLE

FIND$ FIND IN

STRING

LEN$ STRING

LENGTH

RPLC$ REPLACE IN

STRING

DEL$ DELETE

STRING

XCHG$ EXCHANGE

STRING

CLR$ CLEAR

STRING

INS$ INSERT INTO

STRING

LD, AND, OR

=$, <>$, <$,

<=$, >$, >=$

STRING

COMPARI-

SON

--- --- --- ---

Task control

instructions

--- TKON TASK ON TKOF TASK OFF --- ---

Classifica-

tion

Sub-class Mnemonic Instruction Mnemonic Instruction Mnemonic Instruction
