611
Floating-point Math Instructions Section 3-15
Operand Specifications
Description DEG(459) converts the 32-bit floating-point number in S+1 and S from radians
to degrees and places the result in R+1 and R. (The floating point source data
must be in IEEE754 format.)
Radians are converted to degrees by means of the following formula:
Radians
× 180/π = degrees
If the absolute value of the result is greater than the maximum value that can
be expressed as floating-point data, the Overflow Flag will turn ON and the
result will be output as
±∞.
If the absolute value of the result is less than the minimum value that can be
expressed as floating-point data, the Underflow Flag will turn ON and the
result will be output as 0.
Area S R
CIO Area CIO 0000 to CIO 6142
Work Area W000 to W510
Holding Bit Area H000 to H510
Auxiliary Bit Area A000 to A958 A448 to A958
Timer Area T0000 to T4094
Counter Area C0000 to C4094
DM Area D00000 to D32766
EM Area without bank E00000 to E32766
EM Area with bank En_00000 to En_32766
(n = 0 to C)
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants #0000000 to #FFFFFFFF
(binary)
---
Data Registers ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to+2047 ,IR0 to –2048 to+2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
R+1 R
S
S+1
Source (radians, 32-bit floating-point data)
Result (degrees, 32-bit floating-point data)
To Next Page
