Floating-point Math Instructions Section 3-15
Description FSTR(448) expresses the 32-bit floating-point number in S+1 and S
(IEEE754-format) in decimal notation or scientific notation according to the
control data in words C to C+2, converts the number to ASCII text, and out-
puts the result to the destination words starting at D.
The following diagram shows the contents of the 3 control words.
• The content of C (Data format) specifies whether to express the number
in S+1, S in decimal notation or scientific notation.
• Decimal notation
Expresses a real number as an integer and fractional part.
Example: 124.56
• Scientific notation
Expresses a real number as an integer part, fractional part, and expo-
nent part.
Example: 1.2456E-2 (1.2456
×10
-2
)
EM Area with bank En_00000 to
En_32766
(n = 0 to C)
En_00000 to
En_32765
(n = 0 to C)
En_00000 to
En_32767
(n = 0 to C)
Indirect DM/EM
addresses in binary
@ D00000 to
@ D32767
@ E00000 to
@ E32767
@ En_00000 to
@ En_32767
(n = 0 to C)
@ D00000 to
@ D32767
@ E00000 to
@ E32767
@ En_00000 to
@ En_32767
(n = 0 to C)
@ D00000 to
@ D32767
@ E00000 to
@ E32767
@ En_00000 to
@ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to
*D32767
*E00000 to
*E32767
*En_00000 to
*En_32767
(n = 0 to C)
*D00000 to
*D32767
*E00000 to
*E32767
*En_00000 to
*En_32767
(n = 0 to C)
*D00000 to
*D32767
*E00000 to
*E32767
*En_00000 to
*En_32767
(n = 0 to C)
Constants #00000000 to
#FFFFFFFF
(binary)
---
Data Registers ---
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –()IR15
,IR0 to ,IR15
Area S C D
0000 hex: Decimal format
0001 hex: Scientific notation
0002 to 0018 hex (2 to 24 characters, see note)
0000 to 0007 hex (see note)
Note: There are limits on the total number of characters
and the number of fractional digits. See
Limits on the
Number of ASCII Characters on page 643
for details.
Data format
Total characters
Fractional digits
