Instruction Functions Section 2-2

SINGLE BIT

RESET (CS1-H,

CJ1-H, CJ1M, or

CS1D only)

RSTB

@RSTB

!RSTB

!@RSTB

RSTB(533) turns OFF the specified bit in the specified word when the

execution condition is ON.

Unlike the RSET instruction, RSTB(533) can be used to reset a bit in a

DM or EM word.

Output

Required

201

SINGLE BIT

OUTPUT (CS1-H,

CJ1-H, CJ1M, or

CS1D only)

OUTB

@OUTB

!OUTB

OUTB(534) outputs the result (execution condition) of the logical pro-

cessing to the specified bit.

Unlike the OUT instruction, OUTB(534) can be used to control a bit in a

DM or EM word.

Output

Required

204

Instruction

Mnemonic

Code

Symbol/Operand Function Location

Execution

condition

Page

RSTB(533)

D: Word address

N: Bit number

OUTB(534)

D: Word address

N: Bit number
