Table Data Processing Instructions Section 3-17
The following table shows the possible values of C.
R1: First word in range
R1 specifies the first word in the search range. The words from R1 to R1+(C–
1) are searched for the maximum value. (C is the number of words specified in
C.)
Note R1 and R1+(C–1) must be in the same data area.
Operand Specifications
C+1 Data type Index Register output
0000 Unsigned binary No
4000 Unsigned binary Yes
8000 Signed binary No
C000 Signed binary Yes
15 0
C
15 014
0
C+1
13
00 0000 0000 0000
Output selection
Data type
Number of words in range
0: Does not output address to IR00.
1: Outputs address to IR00.
0: Unsigned binary data
1: Signed binary data
R1
R1+(C–1)
15 0
---to
Search range
Area C R1 D
CIO Area CIO 0000 to
CIO 6142
CIO 0000 to CIO 6143
Work Area W000 to W510 W000 to W511
Holding Bit Area H000 to H510 H000 to H511
Auxiliary Bit Area A000 to A958 A000 to A959 A448 to A959
Timer Area T0000 to T4094 T0000 to T4095
Counter Area C0000 to C4094 C0000 to C4095
DM Area D00000 to D32766 D00000 to D32767
EM Area without bank E00000 to E32766 E00000 to E32767
EM Area with bank En_00000 to
En_32766
(n = 0 to C)
En_00000 to En_32767
(n = 0 to C)
