754
Table Data Processing Instructions Section 3-17
Variations
Applicable Program Areas
Operands TB through TB+3: Stack control words
The first four words of the stack contain the PLC memory address of the last
word in the stack and the stack pointer (the PLC memory address of the next
available word in the stack.)
TB+4 through TB+(N–1): Data storage region
The remainder of the stack is used to store data.
Operand Specifications
Variations Executed Each Cycle for ON Condition SDEL(642)
Executed Once for Upward Differentiation @SDEL(642)
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification Not supported.
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
TB
0
15
TB+1
0
15
TB+2
0
15
TB+3
0
15
PLC memory address of the last
word in the stack (rightmost 4 digits)
PLC memory address of the last
word in the stack (leftmost 4 digits)
Stack pointer (rightmost 4 digits)
(Initial value is the rightmost 4 digits of
the PLC memory address for TB+4.)
Stack pointer (leftmost 4 digits)
(Initial value is the leftmost 4 digits of
the PLC memory address for TB+4.)
15 0
TB+4
TB+(N–1)
Data storage region
Area TB C D
CIO Area CIO 0000 to CIO 6143
Work Area W000 to W511
Holding Bit Area H000 to H511
Auxiliary Bit Area A448 to A959 A000 to A959 A448 to A959
Timer Area T0000 to T4095
Counter Area C0000 to C4095
DM Area D00000 to D32767
EM Area without bank E00000 to E32767
