Data Control Instructions Section 3-18
Note P1 to P1+3 must be in the same area.
Operand Specifications
P1
P1+1
P1+2
P1+3
15 0
15
0
15
0
15
0
Scaled value for point A (Ar)
0000 to 9999 (4-digit BCD)
Unscaled value for point A (As)
0000 to FFFF (binary)
Scaled value for point B (Br)
0000 to 9999 (4-digit BCD)
Unscaled value for point B (Bs)
0000 to FFFF (binary)
Area S P1 R
CIO Area CIO 0000 to CIO
6143
CIO 0000 to CIO
6140
CIO 0000 to CIO
6143
Work Area W000 to W511 W000 to W508 W000 to W511
Holding Bit Area H000 to H511 H000 to H508 H000 to H511
Auxiliary Bit Area A000 to A959 A000 to A956 A448 to A959
Timer Area T0000 to T4095 T0000 to T4092 T0000 to T4095
Counter Area C0000 to C4095 C0000 to C4092 C0000 to C4095
DM Area D00000 to
D32767
D00000 to
D32764
D00000 to
D32767
EM Area without bank E00000 to
E32767
E00000 to
E32764
E00000 to
E32767
EM Area with bank En_00000 to
En_32767
(n = 0 to C)
En_00000 to
En_32764
(n = 0 to C)
En_00000 to
En_32767
(n = 0 to C)
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants ---
Data Registers DR0 to DR15 --- DR0 to DR15
