High-speed Counter/Pulse Output Instructions Section 3-21
D: First Destination Word
The PV is output to D or to D and D+1.
Operand Specifications
0002 hex Reads range comparison results. ---
00
@3 hex
P = 0000 or 0001:
Reads the output frequency of
pulse output 0 or pulse output 1.
P = 0010:
Reads the frequency of high-
speed counter input 0.
C = 0003 hex:
Standard operation
C = 0013 hex:
10-ms sampling method for high fre-
quency (supported only by CJ1M
CPU Units Ver. 3.0 or later)
C = 0023 hex:
100-ms sampling method for high
frequency (supported only by CJ1M
CPU Units Ver. 3.0 or later)
C = 0033 hex:
1-s sampling method for high fre-
quency (supported only by CJ1M
CPU Units Ver. 3.0 or later)
C PRV(881) function Variations
D
D+1
0
15
DPV
0
15
Lower word of PV
Upper word of PV
2-word PV
Pulse output PV, high-speed counter input PV,
high-speed counter input frequency for high-speed counter input 0
1-word PV
Interrupt input PV in counter mode, status, range comparison results
Area P C D
CIO Area --- --- CIO 0000 to CIO 6142
Work Area --- --- W000 to W510
Holding Bit Area --- --- H000 to H510
Auxiliary Bit Area --- --- A448 to A958
Timer Area --- --- T0000 to T4094
Counter Area --- --- C0000 to C4094
DM Area --- --- D00000 to D32766
EM Area without bank --- --- ---
EM Area with bank --- --- ---
Indirect DM/EM
addresses in binary
--- --- @ D00000 to @ D32766
Indirect DM/EM
addresses in BCD
--- --- *D00000 to *D32766
Constants See descrip-
tion of oper-
and.
See descrip-
tion of oper-
and.
---
Data Registers --- --- ---
