High-speed Counter/Pulse Output Instructions Section 3-21
S: First Word of Settings Table
The contents of S to S+5 control the pulse output as shown in the following
diagrams.
The actual number of movement pulses that will be output are as follows:
For relative pulse output, the number of movement pulses = the set number of
pulses. For absolute pulse output, the number of movement pulses = the set
number of pulses
− the PV.
F: First Word of Starting Frequency
The starting frequency is given in F and F+1.
Operand Specifications
S1+4
S1+5
S1+2
S1+3
S1
S1+1
0
15
Lower word with number of output pulses
Upper word with number of output pulses
Relative pulse output: 0 to 2,147,483,647
(0000 0000 to 7FFF FFFF hex)
Absolute pulse output: −2,147,483,648 to 2,147,483,647
(8000 0000 to 7FFF FFFF hex)
Lower word with target frequency
Upper word with target frequency
1 to 100,000 Hz
(0000 0000 to 0001 86A0 hex)
Specify the frequency after acceleration in Hz.
Acceleration rate
Deceleration rate
1 to 2,000 Hz (0001 to 07D0 hex)
1 to 2,000 Hz (0001 to 07D0 hex)
Specify the increase or decrease in the frequency per pulse control period (4 ms).
F
F+1
0
15
Lower word with starting frequency
Upper word with starting frequency
0 to 100,000 Hz
(0000 0000 to 0001 86A0 hex)
Specify the starting frequency in Hz.
Area P M S F
CIO Area --- --- CIO 0000 to CIO 6138 CIO 0000 to CIO 6142
Work Area --- --- W000 to W506 W000 to W510
Holding Bit Area --- --- H000 to H506 H000 to H510
Auxiliary Bit Area --- --- A448 to A954 A448 to A958
Timer Area --- --- T0000 to T4090 T0000 to T4094
Counter Area --- --- C0000 to C4090 C0000 to C4094
DM Area --- --- D00000 to D32762 D00000 to D32766
EM Area without bank --- --- --- ---
EM Area with bank --- --- --- ---
Indirect DM/EM
addresses in binary
--- --- @ D00000 to @ D32767 @ D00000 to @ D32767
Indirect DM/EM
addresses in BCD
--- --- *D00000 to *D32767 *D00000 to *D32767
Constants See description
of operand.
See description
of operand.
--- See description of oper-
and.
Data Registers --- --- --- ---
