Step Instructions Section 3-22
000100 LD 000003
000101 OUT W00003
000101 AND 000004
000101 SNXT(009) W00004
000102 STEP(008) W00002
000200 LD 000003
000201 SNXT(009) W00003
000202 STEP(008) W00003
000300 STEP(008) W00004
000400 LD 000005
000401 SNXT(009) 024613
000402 STEP(008) ---
W00003
W00003
W00003
000000 @LD 000001
000001 SNXT(009) W00000
000002 SNXT(009) W00002
000003 STEP(008) W00000
000100 LD 000002
000101 SNXT(009) W00001
000102 STEP(008) W00001
Process A
Process B
Process C
Process D
Process E
Instruction Operands
Process A
started.
Process C
started.
Address
Programming for process A
Process A
reset.
Process B
started.
Used to
turn off
process D.
Process E
started.
Programming for process C
Process C
reset.
Process D
started.
Programming for process D
Programming for process E
Process E
reset.
Programming for process B
