Remove the Main Module
Servicing the Main Module 101
6.
Pull the main module halfway out of the server.
7.
Press the levers back toward the center of the main module.
This will keep the levers from being damaged when the main module is outside the server.
Caution - Due to the weight of the main module, the following step requires two people to
perform. Do not attempt to lift the main module alone.
8.
Remove the main module completely from the server.
9.
Remove the cover from the main module.
