Remove a Processor Module or Processor Filler Module
Servicing Processor Modules 63
4.
Pull the processor module or processor filler module halfway out of the server,
and close the levers.
This protects the levers from damage while the module is outside the server.
5.
Using two hands, completely remove the processor module or procssor filler
module and place the module on an antistatic mat.
Caution - Do not touch the connectors at the rear of the module.
6.
Determine your next step:
■
If you are replacing or installing DIMMs within the processor module, see
“Servicing DIMMs” on page 69.
■
If you are replacing a faulty processor module, populate and install the
replacement processor module:
a.
Remove all of the DIMMs from the faulty processor module, and set
them in a safe place.
See “Remove a DIMM or DIMM Filler Panel” on page 77.
