Error
100 I11 T11 192-120101 N6 - March 2004
Error reaction:
None
Measure:
Load application data into device (IEC61131 program). Turn device off and
back on again.
Note:
Application data error; no IEC61131 program available
LED red flashing
Error code (hex):
0xFF45
Error:
No FBI
Error reaction:
None
Measure:
De-energize motor, then perform function
Note:
Motor is energized! An attempt was made to execute a function at a time
when the motor must be de-energized, e.g. device duplication via BDM.
Error code (hex):
0xFF46
Error:
Motor energized
Error reaction:
None
Measure:
Note:
An attempt was made to perform a device duplication even though the
source and target device are different (different order code)
Error code (hex):
0xFF47
Error:
Different device types
Error reaction:
None
Measure:
Note:
The hardware of the source is not compatible with the hardware of the target
for duplicating a device
Error code (hex):
0xFF90
Error:
Feedback system does not correspond with feedback option
Error reaction:
None
Measure:
„Replace“ or update firmware, use device required for feedback.
Note:
The connected feedback system cannot be used with the firmware currently
in use. (for example with commutation wizard F12 feedback for F10/F11
device and vice-versa).
Error code (hex):
0xFF91
Error:
Invalid combination of hall signals gross commutation
Error reaction:
None
Measure:
Check hall wiring and hall sensors for functionality. Eliminate any (EMC)
malfunctions in hall signals.
Note:
Invalid hall combinations “000“ or “111“ were detected during hall
commutation.
Error code (hex):
0xFF92
Error:
Compax3 must be started again.
Error reaction:
None
Measure:
Switch device off and on again or execute commands 9 and 10 one after the
other.
Note:
Only for F12 devices: Compax3 must be started again, as the commutation
resp. the configured motor was changed by means of a configuration
download. The error cannot be acknowledged.
Error code (hex):
0xFFA1
Error:
SinCos analog signals outside specification
Error reaction:
Reaction 2: downramp / apply brake / deenergize.
Measure:
Change feedback
Note:
Feedback reports error
Error code (hex):
0xFFA2
Error:
SinCos internal angle offset fault
Error reaction:
Reaction 2: downramp / apply brake / deenergize.
Measure:
Change feedback
Note:
Feedback reports error
Error code (hex):
0xFFA3
Error:
SinCos table was destroyed via data field partition
Error reaction:
Reaction 2: downramp / apply brake / deenergize.
0xFF45
0xFF46
0xFF47
0xFF90
0xFF91
0xFF92
0xFFA1
0xFFA2
0xFFA3
