Parker Compax3 S150 V4 User Manual

Setting up Compax3
60 I11 T11 192-120101 N6 - March 2004
1: Target position
2: Travel speed
3. Maximum acceleration
4: Maximum deceleration
5: Maximum jerk (see on page 5) (the same for all positioning data records)
Input window:
A positioning data record has the following contents:
Address Mode Target
position
Posi-
tion
Accele-
ration
Decele-
ration
(delay)
Repetition
number

Parker Compax3 S150 V4 Specifications

General

Output Current	150 A
Control Type	Digital
Series	Compax3
Model	S150 V4
Enclosure Rating	IP20
Communication Interfaces	CANopen, RS-232, RS-485
Feedback Options	Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Relative Humidity	5 to 95% non-condensing
Operating Temperature	0 to +45 °C (32 to 113 °F)
