Parker Compax3 S150 V4 User Manual

Setting up Compax3
72 I11 T11 192-120101 N6 - March 2004
2100.7: D component speed controller
Unit: % Range: 0 ... 4 000 000 Standard value: 0
2100.6: Actual acceleration value filter
Unit: % Range: 0 ... 550 Standard value: 100
2100.4: Moment of inertia
Unit: % Range: 10 ... 500 Standard value: 100%
Forward control measures
Forward control of rotation speed, acceleration and current
! Minimizes tracking error
! Improves the transient response
! Gives greater dynamic range with lower maximum current
A positioning is calculated in the target value plate and specified as the target value
for the position controller. This provides the target value plate with the preliminary
information on changes in speed, acceleration and current required for positioning.
Switching this information to the controller then makes it possible to reduce
tracking errors to a minimum. The transient response of the controller is also
improved and the drive dynamics are increased.
The stability of the control loop is unaffected by the forward control.
Advantages:
Principle:

Parker Compax3 S150 V4 Specifications

General

Output Current	150 A
Control Type	Digital
Series	Compax3
Model	S150 V4
Enclosure Rating	IP20
Communication Interfaces	CANopen, RS-232, RS-485
Feedback Options	Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Relative Humidity	5 to 95% non-condensing
Operating Temperature	0 to +45 °C (32 to 113 °F)
