Setting up Compax3
I11 T11 192-120101 N6 - March 2004 73
Positioning without forward control:
3
4
2
1
t
t
2010.1: Forward speed control
Unit: % Range: 0 ... 500 Standard value: 100%
Effect of the rotation speed forward control
t
t
1
2
3
4
1: target speed value
2: actual speed value
3: motor current
4: tracking error
2010.2: Acceleration forward control
Unit: % Range: 0 ... 500 Standard value: 100%
