Parker Compax3 Series User Manual

Specifications
C3I22T11
396 192-120114 N5 C3I22T11 June 2008
Output data Compax3Mxxx at 3*400VAC
Device type Compax3 M050D6 M100D6 M150D6 M300D6
Power Input
565VDC ±10%
Output voltage
3x 0-400V (0...500Hz)
Nominal output current
5Aeff 10Aeff 15Aeff 30Aeff
Pulse current for 5s *
10Aeff 20Aeff 30Aeff 60Aeff
Power
3.33kVA 6.66kVA 10kVA 20kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
70W+** 90W+** 120W+** 270W+**
*Turning frequency for pulse current: f>5Hz
** Maximum additinal losses with option card 5W.
Output data Compax3Mxxx at 3*480VAC
Device type Compax3 M050D6 M100D6 M150D6 M300D6
Power Input
680VDC ±10%
Output voltage
3x 0-480V (0...500Hz)
Nominal output current
4Aeff 8Arms 12.5Arms 25Arms
Pulse current for 5s *
8Arms 16Arms 25Arms 50Aeff
Power
3.33kVA 6.66kVA 10kVA 20kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
70W+** 90W+** 120W+** 270W+**
*Turning frequency for pulse current: f>5Hz
** Maximum additinal losses with option card 5W.
Output data Compax3Hxxx at 3*400VAC
Controller type H050V4 H090V4 H125V4 H155V4
Output voltage
3x 0-400V
Nominal output current
50Aeff 90Aeff 125Aeff 155Aeff
Pulse current for 5s *
75Aeff 135Aeff 187.5Aeff 232.5Aeff
Power
35kVA 62kVA 86kVA 107kVA
Switching frequency
8 kHz 8 kHz 8 kHz 8 kHz
Power loss for In
880W 900W 1690W 1970W
* during low speeds, the overload time is reduced to 1s. Limit:
< 2.5 electric rev/s (= actual revolutions/s * number of pole pairs) resp. > 2.5 Pitch/s
Output data Compax3Hxxx at 3*480VAC
Controller type H050V4 H090V4 H125V4 H155V4
Output voltage
3x 0-480V
Nominal output current
43Aeff 85Aeff 110Aeff 132Aeff
Pulse current for 5s *
64.5Aeff 127.5Aeff 165Aeff 198Aeff
Power
35kVA 70kVA 91kVA 109kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
850W 1103W 1520W 1800W
* during low speeds, the overload time is reduced to 1s. Limit:
< 2.5 electric rev/s (= actual revolutions/s * number of pole pairs) resp. > 2.5 Pitch/s

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
