Specifications
192-120114 N5 C3I22T11 June 2008 395
Output data Compax3S1xx at 3*230VAC/240VAC
Controller type S100V2 S150V2
Output voltage
3x 0-240V 3x 0-240V
Nominal output current
10Aeff 15Aeff
Pulse current for 5s
20Aeff 30Aeff
Power
4kVA 6kVA
Switching frequency
16kHz 8kHz
Power loss for In
80 W 130W
Output data Compax3Sxxx at 3*400VAC
Controller type S015V4 S038V4 S075V4 S150V4 S300V4
Output voltage
3x 0-400V
Nominal output current
1.5Aeff 3.8Aeff 7.5 Aeff 15Aeff 30Aeff
Pulse current for 5s
4.5Aeff 9.0Aeff 15Aeff 30Aeff 60Aeff
Power
1kVA 2.5kVA 5kVA 10kVA 20kVA
Switching frequency
16kHz 16kHz 16kHz 8kHz 8kHz
Power loss for In
60W 80 W 120W 160W 350W
Output data Compax3Sxxx at 3*480VAC
Controller type S015V4 S038V4 S075V4 S150V4 S300V4
Output voltage
3x 0-480V
Nominal output current
1.5Aeff 3.8Aeff 6.5Aeff 13.9Aeff 30Aeff
Pulse current for 5s
4.5Aeff 7.5 Aeff 15Aeff 30Aeff 60Aeff
Power
1.25kVA 3.1kVA 6.2kVA 11.5kVA 25kVA
Switching frequency
16kHz 16kHz 16kHz 8kHz 8kHz
Power loss for In
60W 80 W 120W 160W 350W
Output data Compax3Mxxx at 3*230VAC
Device type Compax3 M050D6 M100D6 M150D6 M300D6
Power Input
325VDC ±10%
Output voltage
3x 0-230V (0...500Hz)
Nominal output current
5Aeff 10Aeff 15Aeff 30Aeff
Pulse current for 5s *
10Aeff 20Aeff 30Aeff 60Aeff
Power
2kVA 4kVA 6kVA 12kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
70W+** 90W+** 120W+** 270W+**
*Turning frequency for pulse current: f>5Hz
** Maximum additinal losses with option card 5W.

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
