Specifications
C3I22T11
394 192-120114 N5 C3I22T11 June 2008
Mains connection Compax3HxxxV4
Controller type
H050V4 H090V4 H125V4 H155V4
Supply voltage
Three phase 3*400VAC/480VAC
350-528VAC / 50-60Hz
Input current
54Aeff 93Aeff 118Aeff 140Aeff
60A 100A 125A 150A
Maximum fuse rating per
device(=short circuit
rating)
JDDZ class K5,
JDRX class H
JDDZ class H5,
JDRX class H
Control voltage 24VDC Compax3S and Compax3H
Controller type Compax3
Voltage range
21 - 27VDC
Mains module
with switch-on current limitation, due to capaci-
tive load
Fuse
MCB miniature circuit breaker or "delayed ac-
tion fuse", due to capacitive load
Current drain of the device
0.8A
Total current drain
0.8 A + Total load of the digital outputs + cur-
rent for the motor holding brake
Ripple
0.5Vpp
Requirement according to safe extra
low voltage (SELV)
yes
Short-circuit proof
conditional (internally protected with 3.15AT)
Control voltage 24VDC Compax3MP / Compax3M
Device type Compax3MP / Compax3M
Voltage range
21 - 27VDC
Mains module
with switch-on current limitation, due to capaci-
tive load
Fuse
MCB miniature circuit breaker or "delayed ac-
tion fuse", due to capacitive load
Current drain of the device
C3MP10D6: 0.2A
C3MP20D6: 0.3A
Total current drain
C3M050D6: 0.85A
C3M100D6: 0.85A
C3M150D6: 0.85A
C3M300D6: 1.0A
+ Total load of the digital outputs + current for
the motor holding brake
Ripple
0.5Vpp
Requirement according to safe extra
low voltage (SELV)
yes
Short-circuit proof
conditional (internally protected with 3.15AT)
Output data Compax3S0xx at 1*230VAC/240VAC
Controller type S025V2 S063V2
Output voltage
3x 0-240V 3x 0-240V
Nominal output current
2.5Arms 6.3Aeff
Pulse current for 5s
5.5Aeff 12.6Aeff
Power
1kVA 2.5kVA
Switching frequency
16kHz 16kHz
Power loss for In
30W 60W
