Specifications
C3I22T11
408 192-120114 N5 C3I22T11 June 2008
Functions
Operating modes:
 Speed control
 Direct positioning (position control)
 Positioning with set selection
Speed control
 Cyclic predefined Setpoint value
 Up to 2 cyclic actual values
Direct positioning
 Cyclic predefined Setpoint value
 Cyclic actual values
 Different motion functions
Positioning with set selection
 up to 31 motion sets possible.
 Different motion functions
Motion functions
 Absolute positioning
 Relative positioning
 Electronic Gearbox (Gearing)
 Reg-related positioning
(precision < 1µs)
 Speed control
 Stop - Set
 Defining status bits for the sequence
control
 Specification of speed, acceleration, de-
celeration and jerk
 Different machine zero modes
 Absolute / continuous operation
Actual position
 Encoder Simulation
 Resolution: 1 - 16384 increments / revo-
lution
Signal monitor
 2 channels ±10 V analog
 Resolution: 8 Bit

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
