Load position control
Dual Loop Option
2. Feedback system for the control of the load
position is possible.
Signal interfaces
Signal inputs / signal sources
Encoder – input track A/B (RS422)
up to max. 10MHz
internal quadrature of the resolution
Step / direction input (24V-level)
Max. 300kHz at ≥50Ω source impedance
and minimum pulse width of 1,6µs.
+/-10V analog input
14Bit; 62.5µs scanning rate.
SSI Feedback
Signal outputs
Encoder simulation
1...16384 increments/revolution or pitch
Limit frequency 620kHz
Bypass function with encoder feedback
with feedback module F12.(Limit fre-
quency 5MHz).
Signal transmission
HEDA (option M10 or M11)
Exchange of process values:
from Slave to Master
from Slave to Master and
from Slave to Slave.
DeviceNet characteristic data
DeviceNet
Predefined Master/Slave Connection Set
Standard 2.0 Group-2-Slave
Fieldbus I/O Data or Process Data (Pol-
led, COS/Cyclic I/O and Bit Strobe)
Implemented object classes
Identify, Message Router, DeviceNet,
Assembly, Connection, Acknowledge
Handler
Baud rate [kBit/s]
125, 250, 500
permissible cable length
up to 500m on 125Bit/s,
up to 200m on 250Bit/s,
up to 100m on 500Bit/s,
Max. number of nodes
63 Slave
Insulation
Isolated Device Physical Layer
EDS file
C3_DeviceNet.EDS
Conformance (file in the Internet)
Statement of Conformance
http://www.compax3.de/C3_DeviceNet_S
tatement_of_
Conformance.pdf
Further information:
Application example
(C3I22_DeviceNet.ZIP) on the Compax3
CD in the "\Examples" directory
