Environmnental conditions Compax3MP / Compax3M
General ambient conditions
According to EN 60 721-3-1 to 3-3
Climate (temperature/humidity/barometric pres-
sure): Class 3K3
Permissible ambient temperature:
Operation
Storage
Transport
0 to +40 C Class 3K3
–25 to +70 C
–25 to +70 C
Tolerated humidity:
No condensation
Operation
Storage
Transport
<= 85% class 3K3
<= 95%
<= 95%
(Relative humidity)
Elevation of operating site
<=1000m above sea level for 100% load ra-
tings
<=2000m above sea level for 1% / 100m po-
wer reduction
Please inquire for greater elevations
Sealing
IP20 protection class according to EN 60 529
Mechanic resonances:
Class 2M3, 20m/s
2
;8-200Hz
Cooling Compax3MP / Compax3M
Cooling mode:
Forced air ventilation with fan in the heat dissi-
pator
EMC limit values Compax3MP/Compax3M
EMC interference emission
Limit values according to EN 61 800-3,
Limit value class C3 with mains filter.
EMC disturbance immunity
Industrial area limit values in accordance with
EN 61 800-3
EC directives and harmonised EC norms
Low voltage directive
2006/95/EC
EN 61800-5-1, Standard for electric power
drives with settable speed; requirements to
electric safety
EN 60664-1, isolation coordinates for electricale
equipment in low-voltage systems
EN 60 204-1, machinery standard partly applied
EC-EMC-directive
2004/108/EC
EN 61 800-3, EMC norm
Product standard for variable speed drives
COM ports
RS232
115200 baud
Word length: 8 bits, 1 start bit, 1 stop bit
Hardware handshake XON, XOFF
RS485 (2 or 4-wire)
9600, 19200, 38400, 57600 or 115200
baud
Word length 7/8 bit, 1 start bit, 1 stop bit
Parity (can be switched off) even/odd
2 or 4-wire
USB (Compax3M)
USB 2.0 Full Speed compatible
