Parker Compax3 Series User Manual

Parker EME
Specifications
192-120114 N5 C3I22T11 June 2008 405
Environmental conditions Compax3S and Compax3H
General ambient conditions
According to EN 60 721-3-1 to 3-3
Climate (temperature/humidity/barometric pres-
sure): Class 3K3
Permissible ambient temperature:
Operation
Storage
Transport
0 to +45 C Class 3K3
-25 to +70 C Class 2K3
–25 to +70 C Class 2K3
Tolerated humidity:
No condensation
Operation
Storage
Transport
<= 85% class 3K3
<= 95% class 2K3
<= 95% class 2K3
(Relative humidity)
Elevation of operating site
<=1000m above sea level for 100% load ra-
tings
<=2000m above sea level for 1% / 100m po-
wer reduction
Please inquire for greater elevations
Mechanic resonances:
EN 60068-2-6 (sinusoidal excitation)
Sealing
IP20 protection class according to EN 60 529
Cooling Compax3S and Compax3H
Cooling mode:
C3S025V2 ... S150V4: Convection
C3S300V4 & C3H: Forced air ventilation with
fan in the heat dissipator
Air flow rate: 459m
³
/h (C3H)
Supply:
C3S300V4, C3H050, C3H090 internal
C3H125, C3H155 external
220/240VAC: 140W, 2.5µF, Stator - 62Ω
Optionally on request:
110/120VAC: 130W, 10µF, Stator - 16Ω
Circuit breaker: 3A
EMC limit values Compax3S and Compax3H
EMC interference emission
Limit values according to EN 61 800-3,
Limit value class C3/C4 without additional
mains filter:
Information on C2 limit value classes (see
page 16)
EMC disturbance immunity
Industrial area limit values in accordance with
EN 61 800-3

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
