Setting up Compax3
C3I12T11
130
192-120113 N08 C3I12T11 - December 2010
Manual acceleration/deceleration and speed control
You can set the motion profile for moving with JOG+ or JOG- here.
-
-
-
-
1: Manual acceleration / Deceleration
2: Manual speed control
+: I2: MANUAL+ or CW.2
-: I3: MANUAL- or CW.3
