C3I12T11 Function overview
192-120113 N08 C3I12T11 - December 2010
27
The intuitive user interface familiar from many applications, together with the
oscilloscope function, wizards and online help, simplifies making and modifying
settings via the PC.
The optional Operator control module (BDM01/01) (see on page 360) for
Compax3S/F makes it possible to exchange devices quickly without requiring a
PC.
Configuration is made with a PC with the help of the Compax3 ServoManager.
General proceeding (see on page 99)
Configuration

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
