IntelliTouch
®
Control System User’s Guide
109
IntelliFlo VS 3050 and IntelliFlo VSF+SVRS
Warning and Alarm Conditions
The IntelliFlo VS 3050, IntelliFlo VS+SVRS and IntelliFlo VSF+SVRS alarms and warnings are
indicated by flashing LEDs on the control panel. For example, if a “Drive Temperature” warning occurs,
the LED will blink two times, then Off, then blink two times. This sequence is repeated until the condition
is cleared.
• Warning condition: If a warning condition occurs the pump will be continue to run but at a
reduced speed. The Green LED executes a sequence of blinks to indicate which alarm or
warning has occurred.
• Alarm condition: If an alarm condition occurs the pump will drive stop running. The red LED
flashes continuously to indicate the presence of an alarm. The alarm LEDs will reset when the
condition clears.
Note: For IntelliFlo troubleshooting information, see the following manuals: IntelliFlo VS 3050 (P/N
357269) and IntelliFlo VSF+SVRS (P/N 351420)
Number of
time the
LED will
blink
Alarm Description Action
2
Drive Temperature Warning
Excessive drive
temperature
1. Ensure the motor fan has
adequate area for ventilation.
2. Stop motor and allow to cool.
3. Run motor at a higher speed to
improve cooling air flow.
5 Unknown alarm Electron failure 1. Cycle power to reset pump.
2. Replace drive.
6 Drive Temperature Alarm
Excessive drive
temperature
1. Ensure the motor fan has
adequate area for ventilation.
2. Run motor at a higher speed to
improve cooling air flow.
7 Power Out Alarm
Supply voltage
low Ensure proper supply voltage.
8 Over current Alarm
Excessive drive
current
1. Examine fluid/mechanical
system for source of overload.
2. De-energize motor and
determine if motor spins freely.
3. Replace drive.
9 Over voltage Alarm
Excessive volt-
age on drive buss
1. Rapid switching between speeds
can cause excessive voltages
on the drive’s DC buss.
2. Ensure proper supply voltage.
