Pentair INTELLITOUCH User Manual

IntelliTouch
®
Control System User’s Guide
106
Problem: The Quick Touch remote will not work, or will not work dependably.
Symptom Possible Cause Solution
POWER LED does not light
on the Receiver PCB
IntelliTouch Load
Center or Power
Center does not have
power.
Ensure power is being supplied and that the
power center operates correctly without the re-
ceiver installed.
Defective cable or
connection to the
Load Center or Power
Center.
Verify the function of the board using known good
cable set. Check all wiring.
Defective Receiver
board.
Contact Technical Support.
COMM LINK LED does not
light or blink.In normal op-
eration LED will blink at least
every 2 seconds
Defective cable or
connection to the
Load Center or Power
Center.
Verify the function of the board using known good
cable set.
Defective receiver
board.
Replace receiver board.
Address switches are incor-
rectly configured
Verify that the ad-
dress switches on
the transmitter and
handheld receiver
board are correct and
match.
Transmitter battery has failed.
Replace Transmitter
battery Defective Transmitter or Receiver
Contact Technical
Support.

Pentair INTELLITOUCH Specifications

General

Remote Access	Yes, via mobile app
Lighting Control	Yes
Automation	Yes
Expandability	Yes
Interface	Touchscreen, mobile app
Enclosure Rating	NEMA 3R
User Interface	Touchscreen
Compatibility	Pentair equipment
Connectivity	Ethernet, Wireless
Mobile Control	Yes
Remote Control	Yes
Communication Protocol	Pentair proprietary
Control Type	Automated
