THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 2
Jun 1/03
1F2
6-00-00
1. Leading Par
ticulars
and Principal Dimensions
CHART 1 (Sheet 1 of 3)
LEADING PARTICULARS AND PRINCIPAL DIMENSIONS
MODEL PA-32-301FT (6X) PA-32-301XTC (6XT)
ENGINE
Manufacturer Textron Lycoming
Model IO-540-K1G5 TIO-540-AH1A
FAA Type Certificate 1E4
Rated Horsepower 300 HP at Sea Level 300 HP to 12,000 ft.
Rated Speed 2700 RPM 2500 RPM
Oil Pressure (PSI):
Minimum Idling 25
Normal 55
Starting and Warmup 115
Maximum 95
Oil Type and Grade See Lubrication Chart
Oil Sump Capacity 12 U.S quarts (9.25 quarts usable)
Fuel, Aviation Grade
(Minimum and Specified Octane) 100/100LL
Magnetos:
(L/H) Slick 6351 Slick 6361
(R/H) 6350 6360
Magneto Timing 20 degrees BTC
Magneto Point Clearance .010 ± .002
Spark Plugs / Refer to latest revision of Textron
Spark Plug Gap Setting Lycoming Service Instruction No. 1042.
Firing Order 1-4-5-2-3-6
Starter:
Skytech (28 volt) 149-24PM
Alternator (90 amp):
Electrosystems (28 volt) P/N 680-501
Voltage Regulator:
Lamar (28 volt) P/N 584-290
