THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Jun 1/03
4G13
57-00-00
GENERAL
Description
Each wing is an all metal, full cantilever, semi-monocoque type structure with removable tips and access
panels. Attached to each wing are the aileron, flap, main landing gear and fuel tank. The wings are
attached to each side of the fuselage by inserting the butt ends of the main spars into a spar box carry
through. The spar box is an integral part of the fuselage structure which provides, in effect, a continuous
main spar with splices at each side of the fuselage. There are also fore and aft attachments at the front
and rear spars.
NOTE: The major subassemblies of the wing may be removed individually or the wing may be removed
as a unit. To remove a wing, a fuselage and wing supporting cradle is required.
