THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Jun 1/03
3G17
33-00-00
GENERAL
1. Description and Operation
Exterior lighting switches are located in the overhead switch panel. Interior flood/map lights are located
in the overhead switch panel and controlled by adjacent reostats. Instrument panel and avionics lighting
is controlled by separate dimmer switches located below the pilot’s control wheel.
Circuit breakers are located on lower right instrument panel.
2. Troub
leshooting
When checking the lighting system, the master switch must be ON in order for lights to operate. Ensure
also that the appropriate circuit breaker is pushed ON.
