THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 21
Feb 19/04
1D15
5-20-00
6. Scheduled Maintenance - PA-32-301XTC Piper 6XT (S/N’s 3255001 & up) (continued)
Inspection
NATURE OF INSPECTION Interval (Hrs)
50 100
E. FUSELAGE AND EMPENNAGE GROUP (CONT.)
12. Remove, drain, and clean fuel strainer bowl and screen
located in bottom of selector valve ........................................................................ O
13. Inspect fuel pump overboard drain outlet for evidence of fuel discharge.
(See Electric Fuel Pump, 28-20-00.)..................................................................... O O
14. Inspect security of all lines .................................................................................... O
15. Inspect vertical fin and rudder for surface damage or irregularities
(i.e. - skin cracks, distortion, dents, corrosion, and excessive paint build up);
structural defects (i.e. - loose or missing rivets); misrigging or
structural imbalance; hinge damage, excessive wear, freedom of movement
and proper lubrication; and attachment points for missing or worn hardware....... O
16. Inspect rudder hinges, sector and attachments for damage, security,
and operation ........................................................................................................ O
17. Inspect vertical fin attachments for security .......................................................... O
18. Inspect rudder control stops to ensure stops have not loosened
and locknuts are tight ............................................................................................ O
19. Inspect rudder hinge bolts for excess wear. Replace as required......................... O
20. Inspect stabilator and tab for surface damage or irregularities
(i.e. - skin cracks, distortion, dents, corrosion, and excessive paint build up);
structural defects (i.e. - loose or missing rivets); misrigging or
structural imbalance; hinge damage, excessive wear, freedom of movement
and proper lubrication; and attachment points for missing or worn hardware....... O
21. Inspect stabilator tab hinges, horn, and attachments for damage, security,
and operation ........................................................................................................ O
22. Inspect stabilator attachments and attach brackets for corrosion, rust,
and security. Repair as required.
(See Stabilator Attach Brackets Corrosion Inspection, 55-20-00.)........................ O
23. Inspect stabilator and tab hinge bolts and bearings for excess wear.
Replace as required. ............................................................................................. O
24. Inspect stabilator control stops to ensure stops are not loose.
Ensure bolts and locknuts are tight ....................................................................... O
25. Inspect rudder and stabilator cables, fittings, turnbuckles. Check all
cable tensions using a tensiometer (See Notes 11 & 12.) .................................... O
26. Inspect stabilator trim mechanism, stabilator trim cables, fittings,
turnbuckles, guides, and pulleys for safety, damage, and operation.
(See Note 11.)....................................................................................................... O
27. Lubricate per Lubrication Chart, 12-20-00 ............................................................ O O
28. Inspect anti-collision light for security and operation............................................. O O
29. Inspect security of Autopilot bridle cable clamps. (See Note 11.) ......................... O
30. Inspect all control cables, air ducts, electrical leads, lines, radio
antenna leads, and attaching parts for security, routing, chafing,
deterioration, wear, and correct installation. (See Note 11.) ................................. O
31. Inspect ELT battery for condition/date per FAR 91.207......................................... O
32. Inspect ELT installation and antenna for condition/security.
Replace antenna if bent or damaged .................................................................... O
33. Install inspection plates and panels ...................................................................... O
