THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Feb 19/04
5J7
91-33-10
Flood Lights
Figure 1
105232 17.0 NEW / G
101849 16.0 NEW
1
L2A20
FLOOD
LIGHTS
3A
L2B20
BLACK WHITE
1
BLACK WHITE
P1 R1
LEFT OVHD.
FLOOD LT.
RIGHT OVHD.
FLOOD LT.
LEFT
FLOOD LIGHT
DIMMER DIMMER
FLOOD LIGHT
RIGHT
L2C20
L2E20 L2E20
L2C20
CB-27
