(f) Replace ELT access panel and secure with four (4) screws.
(g) In cabin, install positive cable to battery.
(h) Replace cabin rear closeout panel.
(i) Test transmitter.
C. Testing
The transmitter operates on the emergency frequencies of 121.5 and 243.0 MHz; both of these
frequencies are monitored by the various FAA installations. Before performing any operational test
of the ELT, the following precautions should be observed:
CAUTION: TESTING OF AN ELT SHOULD BE CONDUCTED IN A SCREEN ROOM OR METAL
ENCLOSURE TO ENSURE THAT ELECTROMAGNETIC ENERGY IS NOT
RADIATED DURING TESTING. IF A SHIELDED ENCLOSURE IS NOT AVAILABLE,
TESTING MAY BE PERFORMED IN ACCORDANCE WITH THE FOLLOWING
PROCEDURES:
(1) Test should be no longer than three audio sweeps.
(2) Test should be conducted only within the time period made up of the first five minutes after any
hour.
THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 2
Jun 1/03
2I2
25-60-00
