THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Jun 1/03
2I9
27 - CONTENTS
CHAPTER 27 - FLIGHT CONTROLS
TABLE OF CONTENTS
SUBJECT SECTION PA
GE GRID NO.
GENERAL 27-00-00 1 2I11
Description and Operation 1 2I11
Standard Practices and Procedures 1 2I11
Control Cable Inspection 4 2I14
AILERON AND TAB 27-10-00 1 2I21
Troubleshooting 1 2I21
Control Column 1 2I21
Removal 1 2I21
Installation 1 2I21
Flex Joint Replacement 5 2J1
Aileron Control Cables 7 2J3
Removal 7 2J3
Installation 8 2J4
Aileron Bellcrank Assembly 9 2J5
Removal 9 2J5
Installation 9 2J5
Rigging and Adjustment 10 2J6
Aileron - Rudder Interconnect 12 2J8
RUDDER AND TAB 27-20-00 1 2J11
Troubleshooting 1 2J11
Rudder Control Cables 1 2J11
Removal 1 2J11
Installation 1 2J11
Rigging and Adjustment 4 2J14
Rudder Trim Control 6 2J16
Removal 6 2J16
Installation 6 2J16
Rigging and Adjustment 7 2J17
Rudder and Steering Pedal Assembly 8 2J18
Removal 8 2J18
Installation 8 2J18
