THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 8
Feb 19/04
3H22
34-10-00
5. Outside Air T
emper
ature (OAT)
In the standard installation, OAT is provided by a direct reading thermometer mounted in the lower
forward corner of the pilot’s side window.
In 6X S/N’s 3232014 & up and 6XT S/N’s 3255015 & up with the optional Avidyne Entegra Electronic
Flight Display System installed, OAT is provided by the Magnetometer / OAT Sensor Assembly
(Mag/OAT) mounted in the underside of the outboard left wing, which feeds temperature data to the
Primary Flight Display (PFD) and Multifunction Display (MFD).
See Electronic Flight Display System and Magnetometer in 34-20-00 for additional information.
