THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Jun 1/03
4E19
52-30-00
CARGO
1. Baggage Doors
A. Removal
With door open remove hinge pin from hinge and remove the door.
B. Installation
Place door in position so that hinge halves are properly matched and install hinge pin. It will not be
necessary to replace hinge pin with a new pin if it is free of bends and wear.
2. Forw
ard Baggage Door Lock
A. Removal
(1) With door open remove nut from back of lock assembly by use of a special made wrench. (This
tool may be fabricated from dimensions given in 95-00-00, Figure 3.)
(2) Remove lock assembly through front of door.
B. Installation
(1) Place lock into position for installation.
(2) Install nut on lock assembly and tighten with use of a special wrench.
3. Baggage Door Hinges
A. Removal
(1) Remove door from airplane as described in Baggage Doors, Removal.
(2) Remove hinge half from airplane or door by drilling out rivets and removing hinge.
B. Installation
(1) Place hinge halves together and install hinge pin.
(2) Install door into closed position and drill two end rivet holes and install rivets.
(3) Operate door and check for proper fit and installation. Drill remaining holes and install rivets.
