THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 2
Feb 19/04
1E2
5-30-00
Each 1000 Hours
 Replace engine compartment flexible hoses (fuel, oil, etc.) as required; but not to exceed 1000 hours
time-in-service, eight (8) years, or engine overhaul, whichever comes first.
 Overhaul or replace magnetos. (See Note 6, 5-20-00.)
 Clean and lubricate all exterior needle bearings.
 Remove all turbocharger components from the engine. Inspect and repair or replace as necessary.
Inspect turbocharger rotor for excessive play, carbon and dirt deposits. Remove and inspect turbine and
compressor housings. Inspect turbine wheel and impeller for physical damage and excessive build up of
deposits. If excessive, replace turbocharger assembly.
Each 2000 Hours
 Each 2000 hours or seven (7) years, whichever occurs first, remove interior cabinets, panels, and
headliner and conduct detailed inspection of aircraft structure (skin, bulkheads, stringers, etc.) for
condition and security. Inspection of structure concealed by headliner may be accomplished by alternate
means (i.e. - through the use of a borescope) without removing the headliner, providing access is
obtained to all concealed areas and borescope provides sufficient detail to adequately accomplish the
inspection.
 Each 2000 hours, or as specified in the latest revision of Lycoming Service Instruction No. 1009,
overhaul or replace engine.
 At engine overhaul or each 2000 hours, whichever comes first, overhaul or replace alternators.
 Overhaul or replace Hartzell propeller governors each 2000 hours or at engine overhaul. (Verify TBO in
latest revision of Hartzell Service Letter No. 61.)
 Overhaul or replace Hartzell propellers each five (5) or six (6) years or each 2000 or 2400 hours. (Refer
to latest revision of Hartzell Service Letter No. 61 to determine specific requirements for individual
airplanes.)
Each 2400 Hours
 Overhaul or replace Hartzell propellers each five (5) or six (6) years or each 2000 or 2400 hours. (Refer
to latest revision of Hartzell Service Letter No. 61 to determine specific requirements for individual
airplanes.)
2. Per Calendar Year
Each Thirty (30) Days
 Inspect battery, box or shelf, and cables. Flush box as required and fill battery per instructions on box or
in Chapter 24.
Each Ninety (90) Days
 For airplanes equipped with the Avidyne Entegra Electronic Flight Display System: if the Standby
Attitude Indicator has not been operated in the previous 90 days, charge the battery of the Standby
Attitude Indicator. See Standby Attitude Indicator, 34-20-00.
 Remove, drain, and clean fuel strainer bowl and screen located in bottom of fuel selector valve.
