THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Jun 1/03
2F17
24 - CONTENTS
CHAPTER 24 - ELECTRICAL POWER
TABLE OF CONTENTS
SUBJECT SECTION PA
GE GRID NO.
GENERAL 24-00-00 1 2F19
Description and Operation 1 2F19
Troubleshooting 1 2F19
DC GENERATION 24-30-00 1 2G1
Alternator System (90 Amp Electrosystems) 1 2G1
Description 1 2G1
Precautions 5 2G5
On Aircraft Checks 5 2G5
Visual Inspection 5 2G5
Ammeter Validity Test 5 2G5
Battery Supply Voltage Test 6 2G6
Voltage Output No-Load Test 6 2G6
Voltage Output Load Test 6 2G6
Alternator Removal 9 2G9
Bench Tests 9 2G9
Rectifier Ground and Positive Diode Test 9 2G9
Stator Ground and Negative Diode Test 9 2G9
Field Circuit Open or Ground Test 10 2G10
Alternator Overhaul 11 2G11
Disassembly 11 2G11
Cleaning and Inspection 14 2G14
Rotor Continuity Test 14 2G14
Rotor Ground Test 14 2G14
Stator Continuity Test 16 2G16
Stator Ground Test 16 2G16
Diode Testing 16 2G16
Assembly 18 2G18
Alternator Installation 22 2G22
Alternator Belt Tension Adjustment 22 2G22
Battery 22 2G22
Removal 22 2G22
Installation 23 2G23
Testing 23 2G23
Charging 23 2G23
Corrosion Prevention 24 2G24
Checking Voltage Regulator 26 2H2
Checking Overvoltage Relay 26 2H2
