THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Jun 1/03
2H9
24-50-00
ELECTRICAL LOAD DISTRIB
UTION
CHART 3
ELECTRICAL SYSTEM COMPONENT LOADS
Duty Cycle Circuit / Circuit
Cont. Inter. Equipment Breaker (Amps) Optional
X Alternator Field 5 1.5
X Nav Lights 10 3.6
X Anti-Collision Lights 10 3.0
X Landing Light 15 9.0
X Panel Lights / 7.5 1.2
X Switch Lights 1.2
X Courtesy/Reading Lights 5 1.2
X Cockpit Flood Lights 3 0.6
X Fuel Pump 10 1.5
X Engine Gauges 5 8.0
X Elec. Turn & Bank 5 0.28
X Pitot Heat 10 8.0
X Starter Contactor 15 1.47
X Master Contactor — 0.6
X Air Conditioning 10 2.0 X
X Fresh Air Blower 10 8.0 X
