THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 7
Jun 1/033C17
28-10-00
CAUTION: ALL CONTAINERS FOR CEMENTS AND SOLVENTS SHOULD BE
PROPERLY IDENTIFIED.
(c) Repair cement has a pot life of 20 minutes after mixing. The unmixed 80C27 and 80C28
have a shelf life of six months from the date of packaging.
(2) Limitations
NOTE: Fuel cells sustaining damage exceeding the limitations listed below should be
returned for evaluation to: Engineered Fabrics Corporation, 669 Goodyear Street,
Rockmart, Georgia 30153.
(a) FT-192 repair fabric is for repair of simple contours only. Patches referred to in this text are
of this material.
(b) Inside patches are to lap defect edges a minimum of 1.0 inches in each direction.
(c) Outside patches are to lap defect edges 0.25 to 0.50 inches inside patches.
(d) Outside patches are to be applied and cured prior to applying an inside patch.
(e) Blisters between inner liner and fabric larger than 0.25 of an inch in diameter require an
outside and an inside patch.
(f) Separations between layers or plies larger than 0.50 inch in diameter require an outside
and inside patch. Holes and punctures require an outside and inside patch.
(g) Slits or tears up to 6.0 inches maximum length require an outside and inside patch.
(h) External abraded or scuffed areas without fabric damage require an outside patch only.
Repair Kit, Goodyear Part No. 2F1-3-37813
GROUP I MATERIALS: Item Quantity Packaging
80C27 Repair Cement 8 Pint cans (320 grams in each)
80C28 Cross-Linker 8 1 four oz bottle (81 cc in each)
Methylethylketone (MEK) 2 1 pint can
FT-192 Repair Fabric 2 Sheet 12 x 12
AP368 Manual 1
GROUP II MATERIALS *: Item Quantity
Foam Rubber Cloth Sheet, 1/4 x 12 x 12 2
Paint Brush, 1 inch wide 2
Aluminum Plates, 1/4 x 6 x 6 4
Measuring Cup (250 ml) 1
Cellophane (Sheet 12 x 24) 2
* This equipment is necessary to perform the repair. Group II equipment will be furnished at additional
cost, if ordered.
NO
TE: Accessories - order per individual cell requirements.
Phenol plates, phenol plate assemblies and phenol test equipment can be ordered as
required from cell manufacturer.
Alodine 1200 to be ordered as required from cell manufacturer.
Cure Iron (Set 240°F) Optional.
CHART 1
FUEL CELL REPAIR EQUIPMENT
