THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Feb 19/04
5I3
91-23-00
Radio Master Switch
Figure 1
ELECTRIC
BUS
PR1B10
AVIONICS
BUS
PR1A10
A3 A4
PR2B20
X2
X1
RADIO
MASTER
RELAY
PR2A20
SWITCH
MASTER
RADIO
5
64
ON OFF
105232 13.0 NEW / G
