THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Jun 1/03
3C5
28 - CONTENTS
CHAPTER 28 - FUEL
TABLE OF CONTENTS
SUBJECT SECTION PA
GE GRID NO.
GENERAL 28-00-00 1 3C7
Description 1 3C7
Troubleshooting 1 3C7
STORAGE 28-10-00 1 3C11
Fuel System Inspection 1 3C11
Fuel Tanks - Inboard (Aluminum) 1 3C11
Removal 1 3C11
Installation 1 3C11
Fuel Tank / Wing Spar Corrosion Inspection 2 3C12
Fuel Cells - Outboard (Bladder-type) 2 3C12
Removal 2 3C12
Cleaning 4 3C14
Inspection 4 3C14
Installation 4 3C14
Handling and Storage 6 3C16
Repair 6 3C16
Handling of Repair Materials 6 3C16
Limitations 7 3C17
Heat Cure Repair Patch Method 8 3C18
Air Cure Repair Patch Method 9 3C19
Fuel Cell Defect Repairs 9 3C19
Molded Nipple Fittings Installation 10 3C20
Accessory Replacement 10 3C20
Testing 10 3C20
Locking Fuel Cap 11 3C21
Disassembly 11 3C21
Assembly 11 3C21
DISTRIB
UTION
28-20-00 1 3D1
Cleaning Fuel System 1 3D1
Cleaning Filter Assembly 1 3D1
Fuel Selector Valve and Filter Assembly 2 3D2
Removal 2 3D2
Installation 2 3D2
Flush Lines 2 3D2
Electric Fuel Pump 4 3D4
Inspection 4 3D4
Removal 4 3D4
Installation 4 3D4
