THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Feb 19/04
5I15
91-28-20
Fuel Pump
Figure 1
Q2A18
FUEL
PUMP
10A
Q2B18
2
3
Q2C18
Q2G18N
FUEL PUMP
SWITCH
FUEL
PUMP
FILTER
R4P4
Q2D18
Q2E18
Q2F18
Q2G18
CB-10
R2
P2
P9 R9
R9 P9 P4 R4
105232 7.0 NEW / G
101849 7.0 NEW
8 8
7 77 7
8 8
5 5
