THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 4
Jun 1/03
2J14
27-20-00
(d) Set cable tension and check rigging adjustment per Rigging and Adjustment, below.
(e) Install tail cone and secure with screws.
(f) Install the access panel to the aft section of the fuselage.
(2) To install forward rudder control cables:
NOTE: Aft cable(s) must be installed before installing forward cable(s), see above.
(a) Draw control cable through floor tunnel.
(b) Connect end of cable to arm on rudder pedal torque tube by installing bolt, washer, nut
and cotter pin. Ensure cable end is free to rotate.
(c) Connect forward cable to aft control cable at turnbuckles in aft section of fuselage. Ensure
each cable is in the groove of its pulley.
(d) Move cable guard, located in forward tunnel under pulley cluster and below the fuel
selector, into position, and secure with cotter pin.
(e) Install cable guard blocks, located within floor opening aft of main spar, onto spar housing.
Secure with screws.
(f) Install cable guard pin at pulley cluster in aft area of floor opening by sliding it into position
and fastening with a cotter pin.
(g) Install cable guard plate under pulley cluster located in aft area of aft floor tunnel. Secure
with screws.
(h) Set cable tension and check rigging adjustment per Rigging and Adjustment, below.
(i) Install heat duct. Secure with screws.
(j) Install forward tunnel plate aft of tee bar. Secure with screws.
(k) Put floor carpet in place and secure.
(l) Place fuel selector lever on selector torque tube. Secure with pin and cotter pin.
(m) Install lower and upper selector covers. Secure with screws.
(n) Install floor panel and seat belt attachment aft of main spar. Secure panel with screws.
(o) Install seats.
(p) Install cover and carpet of aft floor tunnel.
C. Rigging and Adjustment
CAUTION: VERIFY FREE AND CORRECT MOVEMENT OF RUDDER. WHILE IT WOULD SEEM
SELF-EVIDENT, FIELD EXPERIENCE HAS SHOWN THAT THIS CHECK IS
FREQUENTLY MISINTERPRETED OR NOT PERFORMED AT ALL. ACCORDINGLY,
UPON COMPLETION OF RUDDER RIGGING AND ADJUSTMENT, VERIFY THAT
THE RUDDER MOVES RIGHT WHEN THE RIGHT PEDAL IS DEPRESSED; AND,
THAT THE RUDDER MOVES LEFT WHEN THE LEFT PEDAL IS DEPRESSED.
(1) Remove tail cone fairing and aft fuselage access panel.
CAUTION: TO AVOID CABLE STRETCH, DO NOT PUSH RUDDER HARDER THAN
NECESSARY.
(2) Using a suitable tool, as shown in Figure 2, set the rudder stops (see Figure 3) so that rudder
travel is as specified in Figure 4, measured from neutral (i. e. - streamlined with the vertical
stabilizer). (See 95-00-00, Figure 5, for tool fabrication instructions.)
(3) Install a suitable tool which will streamline the rudder with the vertical stabilizer and lock it in
that position.
