THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Jun 1/03
4G15
57-20-00
AXUILIARY STRUCTURE
Wing Tip
A. Removal
(a) Remove the screws holding the wing tip to the wing, being careful not to damage the wing or
wing tip.
(b) Pull off the wing tip far enough to disconnect the landing light and navigation and strobe light
wire assemblies. Be sure to unscrew the ground lead at the wing rib.
(c) Inspect the wing tip to ascertain that it is free of cracks, severe nicks and minor damage. If
repair is required, refer to Repair, below.
B. Installation
(a) Place the wing tip in a position that the landing light and navigation and strobe light leads may
be connected. Be sure to connect the navigation/strobe ground lead to the wing rib by use of a
screw and nut. Ensure that the ground lead is free of dirt and film to insure a good connection.
(b) Insert the wing tip into position and install the screws round the tip. Take care to refrain from
damaging the wing tip or wing. Check operation of the lights.
C. Repair
See 51-00-00.
