THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Feb 19/04
5I17
91-28-40
Fuel Quantity
Figure 1 (Sheet 1 of 2)
6
R1
6
P1
+
LEFT
GND
RIGHT
Q3D20
Q1G20N
FUEL
QTY
Q1A20
3A
Q4D20
55
R1 P1
TERMINAL
STRIP
RED
R. OUTBD
SENDER
910
Q3C20
Q3B20
SENDER
R. INBD
Q4C20
L. OUTBD
SENDER
RED
Q4B20
L. INBD
SENDER
GB1-K
CB-9
105232 6.0 NEW / G
DUAL
FUEL QUANTITY
INDICATOR
Effectivity
3232001 & up
3255001 & up
