THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 1
Feb 19/04
5I9
91-24-40
External Power
Figure 1
EXTERNAL
POWER
CONTACTOR
EXTERNAL
POWER
RECEPTACLE
-
+
P20A4
P22A20
TO BATTERY MASTER SOLENOID
(SEE 91-24-30, FIGURE 1)
105232 23.0 NEW / G
101849 22.0 NEW
